Belt shaped central bundle tube optical cable product series
Product Application:
This optical cable is suitable for wiring in access networks, especially in backbone loops
This optical cable is suitable for laying through pipelines and non self supporting overhead methods
Product Features:
High fiber density;
Excellent waterproof performance;
Good temperature performance;
Four steel wires provide superior mechanical properties;
The fiber optic cable has a small size, making it easier to lay and saving costs.
Operating temperature: -40 ℃ to+70 ℃
transmission performance
| Fiber type | 62.5μm（OM1） 850nm/1300nm | 50μm（OM2） 850nm/1300nm | G.652 1310nm/1550nm | G.655 1550nm/1625nm |
| Maximum attenuation value (dB/km) | 3.5/1.5 | 3.5/1.5 | 0.36/0.22 | 0.22/0.26 |
| Typical attenuation value (dB/km) | 3.5/1.5 | 3.0/1.0 | 0.35/0.21 | 0.21/0.24 |
Note: Other optical fibers that meet user needs can also be provided
GYDXTW
Product Structure Diagram:
Product Description: How to Translate
GYDXTW (Fiber Optic Tape, Central Tube Structure, Steel Polyethylene Adhesive Sheath)
Execution standard:
YD/T 981.2-2009 Fiber optic ribbon cables for access networks
Technical parameters (typical values):
| core count | structure | outer diameter（mm） | weight（kg/km） | Stretching force（N） long-term short-term | Flattening force（N） long-term short-term | bend radius（mm） static dynamic |
|
|
|
| 48 | central tube | 13.0 | 165 | 600 | 1500 | 300 | 1000 | 10D | 20D |
| 60 | central tube | 13.9 | 185 | 600 | 1500 | 300 | 1000 | 10D | 20D |
| 72 | central tube | 13.9 | 185 | 600 | 1500 | 300 | 1000 | 10D | 20D |
| 84 | central tube | 14.4 | 195 | 600 | 0.8G | 300 | 1000 | 10D | 20D |
| 96 | central tube | 14.4 | 195 | 600 | 0.8G | 300 | 1000 | 10D | 20D |
| 108 | central tube | 15.1 | 215 | 600 | 0.8G | 300 | 1000 | 10D | 20D |
| 120 | central tube | 15.1 | 215 | 600 | 0.8G | 300 | 1000 | 10D | 20D |
| 132 | central tube | 15.7 | 230 | 600 | 0.8G | 300 | 1000 | 10D | 20D |
| 144 | central tube | 15.7 | 230 | 600 | 0.8G | 300 | 1000 | 10D | 20D |
| 168 | central tube | 16.4 | 250 | 600 | 0.8G | 300 | 1000 | 10D | 20D |
| 192 | central tube | 16.9 | 270 | 600 | 0.8G | 300 | 1000 | 10D | 20D |
| 216 | central tube | 17.5 | 280 | 600 | 0.8G | 300 | 1000 | 10D | 20D |
note
D refers to the diameter of the optical cable;
Corresponding technical parameters can be adjusted according to customer needs;
The water blocking method can be adjusted according to customer needs;
Specific designs for flame-retardant, rodent proof, and ant proof optical cables can be made according to customer needs.
