GYDXTW

Product Description: How to Translate

GYDXTW (Fiber Optic Tape, Central Tube Structure, Cable Paste Filling, Steel Polyethylene Adhesive Sheath)


Execution standard:

YD/T 981.2-2009 Fiber optic ribbon cables for access networks

咨询产品
Product Details

GYDXTW

Fiber optic ribbon, central tube structure, cable paste filling, steel polyethylene adhesive sheath

Product Description: How to Translate

GYDXTW (Fiber Optic Tape, Central Tube Structure, Cable Paste Filling, Steel Polyethylene Adhesive Sheath)


Execution standard:

YD/T 981.2-2009 Fiber optic ribbon cables for access networks


Technical parameters (typical values):

core countstructure

Outer diameter (mm)

Weight (kg/km)

Tensile force (N)

long-term   short-term

Flattening force (N)

long-term   short-term

Bending radius (mm)

static   dynamic

48central tube13.51716001500300100010D20D
72central tube14.31906001500300100010D20D
144central tube16.52506001500300100010D20D
216central tube18.53106001500300100010D20D
288central tube19.23356001500300100010D20D

note

  1. D refers to the diameter of the optical cable;

  2. Corresponding technical parameters can be adjusted according to customer needs;

  3. The water blocking method can be adjusted according to customer needs;

  4. Specific designs for flame-retardant, rodent proof, and ant proof optical cables can be made according to customer needs.
