GYDTS
Fiber optic ribbon, loose layer twisted structure, metal reinforcement, cable paste filling, steel polyethylene adhesive sheath
Product Description:
GYDTS (Fiber Optic Tape, Loose Layer Twisted Structure, Metal Reinforcement, Cable Paste Filling, Steel Polyethylene Adhesive Sheath)
Execution standard:
YD/T 981.3-2009 Fiber optic ribbon cables for access networks
Technical parameters (typical values):
| core count | structure | Outer diameter (mm) | Weight (kg/km) | Tensile force (N) long-term short-term | Flattening force (N) long-term short-term | Bending radius (mm) static dynamic |
| 48-144 | 1+4 | 17.2 | 276 | 600 | 1500 | 300 | 1000 | 10D | 20D |
| 156-192 | 1+4 | 17.2 | 283 | 600 | 1500 | 300 | 1000 | 10D | 20D |
| 194-216 | 1+4 | 18.7 | 334 | 600 | 1500 | 300 | 1000 | 10D | 20D |
| 218-288 | 1+4 | 18.7 | 337 | 600 | 1500 | 300 | 1000 | 10D | 20D |
| 290-432 | 1+4 | 20.6 | 400 | 600 | 1500 | 300 | 1000 | 10D | 20D |
| 434-576 | 1+4 | 20.6 | 478 | 600 | 1500 | 300 | 1000 | 10D | 20D |
note
D refers to the diameter of the optical cable;
Corresponding technical parameters can be adjusted according to customer needs;
The water blocking method can be adjusted according to customer needs;
Specific designs for flame-retardant, rodent proof, and ant proof optical cables can be made according to customer needs.
