Product series of optoelectronic hybrid cables for access networks
Product Application：
This optical cable is mainly used in DC remote power supply systems or areas with inconvenient power access
Mainly solve the communication and power supply problems of FTTH or mobile communication network terminal equipment
Product Features：
Can simultaneously achieve optical communication and power transmission；
Excellent lateral compression resistance, tensile strength, and good temperature performance;
Each unit cable can be directly terminated with standard connectors, reducing construction and network construction costs
Operating temperature: -40 ℃ to+70 ℃
transmission performance
| Fiber type | 62.5μm（OM1） 850nm/1300nm | 50μm（OM2） 850nm/1300n | G. 652 1310nm/1550nm | G. 655 1550nm/1625n |
| Maximum attenuation value (dB/km) | 3.5/1.5 | 3.5/1.5 | 0. 36/0. 22 | 0. 22/0. 26 |
| Typical attenuation value (dB/km) | 3.5/1.5 | 3.0/1.0 | 0. 35/0. 21 | 0. 21/0. 24 |
Note: Other optical fibers that meet user needs can also be provided
GDFJU
Product Structure Diagram:
Product Description: How to Translate
GDFJU (non-metallic reinforcement components, tight fitting optical fibers, feeder lines, TPU outer sheath communication cables for outdoor use)
Execution standard:
YD/T 2159-2010 Optoelectronic Hybrid Cable for Access Network
Technical parameters (typical values):
core count | Specifications | structure | cable diameter | Weight (kg/km) | Tensile force (N) long-term short-term | Flattening force (N) long-term short-term | Bending radius (mm) static dynamic |
|
|
|
| 4 | 3*1.0+4F | 1+7 | 12.3 | 145 | 600
| 1500 | 300 | 1000 | 10D
| 20D |
note
D refers to the diameter of the optical cable;
Corresponding technical parameters can be adjusted according to customer needs;
Specific designs for flame-retardant, rodent proof, and ant proof optical cables can be made according to customer needs.
